Classified ID : 765
2000 KVA 3PH Pad Mount Transformer 34500Y/19920 to 480Y/277 with Taps Above and Below -- 658279
Start Time:05/17/2018 15:36:44 CDT
End Time:02/11/2023 08:53:07 CDT
Location: South Dakota, 57450
Country: USA
Time Left: Time Ended
2000 KVA Three Phase Pad Mount Transformer Primary Voltage: 34500Y/19920 Secondary Voltage: 480Y/277 W/Taps 2 X 2 1/2% +/- Make: Delta Star Impedance: 3.45 Weight: 14500 Gallons of Oil: 738 Dimensions Height: 93 Width: 85 Depth: 47 ** All dimensions are approximate and should not be used for engineering purposes. S/N: H69023 Stock Number: 658279 Website:!i=658279 Reconditioned Items * This item is subject to the Standard Terms and Conditions of Sale. * Allow 4 - 6 weeks for this unit to be ready for shipment. This lead-time is based on our production backlog as of date of the listing and is subject to change. * Unless otherwise specified, freight on units quoted is prepaid and allowed in the contiguous 48 US with our Contracted Carrier on their next available truck going to your area. * Upon order completion, immediate shipment is available and the cost can be paid by the buyer on a common carrier of their choice. * Items listed are subject to prior sale and results of final test. * Add $100.00 if a pallet for this item is required and must be requested at time of payment or deposit * Buyer must place a non refundable 10% deposit within 24 hrs after listing is closed. Net 30 terms are available for balance upon credit approval. Shipping will not take place until payment is received or net 30 terms are established. * Item(s) are used and will be reconditioned and guaranteed by T and R Electric Supply Co., Inc and not by the original manufacturer. Questions, contact Dan Bowen 1-800-843-7994 Ext 2185 or email * Pictures shown will be the actual unit unless otherwise specified as a stock photo in this listing. Call 866-972-9830 or email us at for a freight quote today!
Power Phase Type : Three
Capacity KVA : 2000 MVA : -
Voltages Pri-Voltage : 34500Y/19920 Sec Voltage : 480Y/277 Taps : W/Taps 2 X 2 1/2% +/-
Other Impedance : 3.45
Record Serial Num : H69023 Manufacturer : Delta Star Part Number : - Stock Number : 658279
Dimensions Height : 93 Width : 85 Depth : 47
